Description

• 1. Size : ID2,413mm x 20,520mmAOL / Weight 102.8Ton
• 2. Material
  1) Shell : SA516 Gr.70 Normalized
  2) Tube : SA213 Type 316L
  3) Tubesheet : SA266 Cl.2 w/316LSS Cladding
• 3. TEMA Type : AKL (Horizontal)
• 4. Certificate : ASME “U” Stamp w/National Board

Description

• 1. Size : Size : ID1,230mm x 13,270mmAOL / Weight 20.3Ton
• 2. Material
  1) Shell : SA516 Gr.70 Normalized
  2) Tube : SA789 – S32205
  3) Tubesheet : SA266 Cl.2 w/S32205 Cladding
• 3. TEMA Type : NFN (Horizontal)
• 4. Certificate : ASME “U” Stamp w/National Board

Description

• 1. Size : ID2,020mm x 11,820mmAOL / Weight 35.3Ton
• 2. Material
  1) Shell : SA516 Gr.70 Normalized
  2) Tube : SA789 – S32205
  3) Tubesheet : SA266 Cl.2 w/S32205 Cladding
• 3. TEMA Type : NFN (Horizontal)
• 4. Certificate : ASME “U” Stamp w/National Board

Description

• 1. Size : Size : ID2,000mm x 7,420mmTL to TL / Weight 14.5Ton
• 2. Material
  1) Shell : SA516 Gr.70 Normalized
  2) Head : SA516 Gr.70 Normalized
  3) Forging/Flange : SA105 Normalized
• 3. Certificate : ASME “U” Stamp w/National Board

Description

• 1. Size : ID2,200mm x 2,980mmTL to TL / Weight 11.4Ton
• 2. Material
  1) Shell : SA516 Gr.70 Normalized
  2) Head : SA516 Gr.70 Normalized
  3) Forging/Flange : SA105 Normalized
• 3. Certificate : ASME “U” Stamp w/National Board

Description

• 1. Size : Width5,200mm x Height7,000mm x Length11,000mm Weight 42Ton
• 2. Material : SA516 Gr.70
• 3. Remarks
  * Knock-Out Drum 1 set & S/T Heat Exchanger 1 set * Fuel Gas Filter 2 sets & Prefilter 2 sets * Control Valves and Instruments

Description

• 1. Size : Width4,600mm x Height8,900mm x Length8,500mm Weight 22Ton
• 2. Material : SA240-316L / Duplex Stainless Steel S31803
• 3. Remarks
  * 4-Off Filters * 82-Off DSS(S31803) Valves * Junction Box, Control Valves and Instruments
• Certificate : ASME “U” Stamp

Description

• 1. Size : Width1,600mm x Height2,600mm x Length1,800mm Weight 2.5Ton
• 2. Material : SA240-316L / Design Temperature : -196 deg.C
• 3. Remarks
  * 2-Off Cryogenic Filters * 26-Off Cryogenic Ball Valves * 2-Off Cryogenic Safety Valves * 1-Off Pressure Differential Indicator Transmitter
• Certificate : DNV-GL Class I / ABS Class I

Description

• 1. Size : Width 3,500mm x Height 4,300mm x Length 13,700mm Weight 25Ton
• 2. Material : SA516-70
• 3. Remarks
  * 5-Off Bulk Filter, Pre-Filters & Coalescer * 7-Off AOV(Air Operated Valve) / * 5-Off Safety Valves * Instruments & Manual Valves
• Certificate : ISHL
